The SolaX X1-IES 4.6kW is an advanced all-in-one residential energy storage system designed to maximise solar self-consumption and provide reliable backup power. Combining a high-performance 4.6kW single-phase hybrid inverter with expandable battery storage from 5kWh to 20kWh, the system offers a simple, space-saving solution for homeowners looking to reduce energy costs and increase energy independence.
Its plug-and-play design simplifies installation while supporting up to 200% PV oversizing and 20A DC input current, making it compatible with the latest high-power solar panels. The integrated battery system delivers up to 50A charge and discharge current, while UPS-level switchover in less than 10ms ensures uninterrupted power to essential loads during grid outages.
The X1-IES includes smart energy management features such as load control for heat pumps and EV chargers, micro-grid functionality, intelligent scheduling, and VPP readiness. With global MPPT scanning, Type II surge protection, optional AFCI protection, and an IP66-rated enclosure, the system is built for both performance and long-term reliability.
Key Features
4.6kW single-phase hybrid inverter
Expandable battery capacity from 5kWh to 20kWh
All-in-one plug-and-play design
Up to 20A DC input current
200% PV oversizing capability
50A charge/discharge current
UPS backup switchover <10ms
Up to 200% EPS output for 10 seconds
Smart load management
VPP and micro-grid ready
Global MPPT scanning
Type II AC & DC SPD protection
Optional AFCI protection
IP66 weatherproof rating
Battery cycle life >6,000 cycles
